M10100 Medical round bar CNC precision Centerless Grinding machines

Product Description

Recommend Products
Product Description
Introduction
Centerless grinder is a kind of grinding machine which does not need to use the axis positioning of the workpiece. It is mainly composed of grinding wheel, adjusting wheel and workpiece bracket.
The grinding wheel actually acts as the grinding work. The adjusting wheel controls the rotation of the workpiece and controls the feed speed of the workpiece.
Salient features
For Grinding wheel and Regulating wheel
⭕The grinding wheel designed in cantilever type, and its spindle adopted multi-plate long bearing bushed
static-hydrodynamical oil film bearing.
Cantilevered regulating wheel, the spindle supports solid bearing sliding with 1:30 taper.
Use lubricating oil alone on the spindle.
The regulating wheel feed slide is supported on Flat-V hydraulic unloaded guideway.
Electric control

AC frequency converter is used for regulating wheel speed control .
Hydraulic transmission & stepless speed regulation are adopted on regulating wheel & grinding wheel dresser.

Machine design and body

⭕Equipped automatic plunge device in the grinder.
Iron casting with high rigidity, natural aging.
Specification
Thru-feed
1)Grinding diameter
10-100mm
2)Grinding length
210mm
Plunge feed
1)Grinding diameter
10-100mm
2)Grinding length
195mm
Grinding wheel specifications
P500*200*305mm
Regulating wheel specifications
PSA350*200*127mm
Grinding wheel speed
1250r/min
Regulating wheel speed(stepless)
10-200r/min
Swiveling angle of regulating wheel
1)In vertical plane
-2°~ 5°
2)In horizontal plane
0°~ 3°
Feed amount per division of the feed handwheel
0.002mm
Feed amount per division of the dresser
0.01mm
Height from centerline of gri.wheel & reg.wheel to workrest
255mm
Total power of machine
21.66kw
1)Grinding wheel motor
18.5kw
2)Regulating wheel motor
2.2kw
Power supply
3 phase, 415 V, 50 Hz
Overall dimensions
2675*1505*1615mm
Machine weight
about 4500kg
Accuracy for fine grinding of standard bars
1)Roundness
0.002mm
2)Cylindricity
0.003mm
3)Surface Roughness
Ra0.32um
Company Profile
Our Service
Overseas after sales service outlets
TOPTECH SMAC MACHINERY LIMITED(Canada)
Address:Office and showroom, unit 5, 5510 Ambler Dr Mississauga, ON, L4W2V1, CANADA
Office:905 238 8912
Contact: Mrs Merry NA

COMPANY REPRESENTATIVE (EGYPT)
Address: Ibn Khaldon St. -Villa No.16-6th District-Obour City-Cairo-Egypt
Tel & Fax: +20244823499
Cell phone: +201223960211
Contact: Ahmed Refaat

SJR MACHINERY LIMITED(Algeria)
Adress: cité 128 logements Bater numéro 71 Sidi el DJILLALI sidi bel abbes 22000 att to Mr mezouar Mohammed
mobile number 0542 695 457 and 0770 551 807
Tel: 0542 695 457 ,0770 551 807
Email:Mezouarstar@gmail.com
Packing & Delivery
We choose the best packaging, the most excellent logistics services, to ensure that your goods faster and safer to reach the destination.

Customer Photos
FAQ
Q.What are your normal lead times?
A.Our company typical lead times range from 3-4weeks after receipt of order.

Q.What are the terms of payments you offer?
A.We accept payment of T/T, L/C, and Western Union, cash, O/A etc.

Q.What kind of package do you offer?
A.Normally in plywood case, to make sure all goods in good condition.

Q.What is the MOQ for your production?
A.The MOQ depends on your requirements for color, logo and so on. For some normal items, we have in stock, the MOQ is 1 set.

Q.Do you have CE certification
A.Yes, we have CE certification, machine quality is one year guaranteed.

Q.How to control the quality of the products?
A.We have always placed great emphasis on the quality level is maintained. Moreover, the principle we always maintain is "to provide customers better quality, better price, and better service".
