Automatic CNC Wire EDM High Taper Metal Cutting Machine

Product Description

Product Description The EDM is mainly composed of machine tool, numerical control system and high frequency power supply. The CNC system is composed of single chip microcomputer, keyboard and frequency conversion detection system, which has the main functions of gap compensation, linear interpolation, arc interpolation, automatic processing of broken wire, etc. It can cut materials such as high strength, high toughness, high hardness, high brittleness, magnetic materials, and precise and small parts with complex shape.

The power supply adopts advanced and unique pulse power supply, which can output super large current, realize high speed, output super small pulse width, realize high precision and high finish.
Servo x-axis and y-axis drive adopts imported famous brand AC servo drive system, closed-loop control, more stable machining accuracy and higher multiple cutting accuracy.


The newly developed CNC system, international brand industrial computer and cutting software can control the wire conveying speed and high-frequency parameter output according to the different material and thickness of workpiece processed by users, which greatly improves the finish after multiple cutting, and can stably reach RA ≤ 0.8um Specification
Specification
Model
16101 DK7725
16104 DK7732
16105 DK7740
16106 DK7763
16107 DK7780
Table size
520 x 336 (mm)
576 x 366 (mm)
690 x 410 (mm)
1100 x 720 (mm)
1300 x 820 (mm)
Table travel X/Y workpiece
250 x 320 (mm)
320 x 400 (mm)
400 x 500 (mm)
630 x 800 (mm)
1000 x 820 (mm)
Thickness
400mm
400mm
400mm
500mm
500mm
Taper
6°/80mm
6°-30°/80mm
6°-30°/80mm
6°-30°/80mm
6°-200mm
Max machining speed
100mm2/min
Roughness
Ra ≤2.5μm
Wire diameter
Φ0.1-Φ0.2mm
Wire travel speed
11m/s
Working liquid
DX-1 DX-4-1
Accuracy standard
G7926-87
Plus
0.001mm
Power consumption
≤1.2KW
Table loading
120kg
250kg
320kg
1000kg
1200kg
Weight
950kg
1100kg
1800kg
4000kg
5000kg
Overall size
1300x900x1465mm
1380x920x1465mm
1500x970x1465mm
2200x1900x1700mm
2900x2800x2500mm
Packing
1600x1100x1800mm
1700x1200x1800mm
1800x1200x1900mm
2600x2150x2100mm
3200x3100x2800mm
